Description
Warranty
10-year warranty / 4500 cycles (9000 cycles on BMS display)
(20 – 30 years service life)
Details
- Bulk + Absorption: 56.2V
- Float: 56.2V
- Low Voltage Cut Off: 44V
- Charge for Parallel Units: (100A*Units in parallel*) /2
- Discharge for Parallel Units: 200A*Units in parallel*)
Module Basic Parameter
- Module Nominal Voltage (V): 51.2V
- Module Nominal Capacity (Ah): 104Ah
- Module Nominal Power (kWh): >5.2kWh @ 0.4c (Tested)
- Dimensions (mm): 630mm 345mm * 137mm
- Weight (Kg): 42KG
- Discharge Cut-Off Voltage (V): 44V
- Charge Voltage (Bulk Absorption) (V): 56.2V
- Max Discharge Current (A): 100A
- Remmended Charge Current: 50A
- Communication Interface: Can
- Configuration: 16S
- Operating Temperature: 0 ~ 50 °C (Charge), – 20 ~ 50 °C (Discharge) -20 ~ 55 °C (Storage)
- Cell Chemistry: Lithium Iron Phosphate (LiFePO4)
- Cycle Life: ≥80% Capacity State After 4800 Cycles at 0.5C, 25°C, 100% DOD
- IP Level: IP 20
